Features
- Ultra bright luminous output
- Two chips are matched for uniform light output
- Wide viewing angle
- Long life-solid state reliability
- I.C.compatible/Low power consumption
- Pb free & Hg free
- RoHS compliant
Applications
- Indication lights
- TV set, Monitor, Telephone, Computer.
| Part Number |
Chip |
Lens Color |
VF(V)If=20mA |
IV(mcd)If=20mA |
Angle
2θ1/2 |
| Emitted Color |
Wave Length λD(nm) |
Min |
Max |
Min |
Max |
| 5RG5AC |
Red |
620-635 |
Water Clear |
1.9 |
2.5 |
150 |
400 |
30-40 |
| Green |
565-575 |
Water Clear |
1.9 |
2.5 |
100 |
300 |
30-40 |
| 5RG5BC |
Red |
620-635 |
Water Clear |
1.9 |
2.5 |
600 |
1300 |
30-40 |
| Green |
565-575 |
Water Clear |
1.9 |
2.5 |
500 |
1000 |
30-40 |
| 5YGAC |
Yellow |
580-595 |
Water Clear |
1.9 |
2.5 |
150 |
400 |
30-40 |
| Green |
565-575 |
Water Clear |
1.9 |
2.5 |
100 |
300 |
30-40 |
| 5RBCC |
Red |
620-635 |
Water Clear |
1.9 |
2.5 |
1500 |
2200 |
30-40 |
| Blue |
460-470 |
Water Clear |
2.9 |
3.5 |
1300 |
2000 |
30-40 |
| 5YG4CC |
Yellow |
580-595 |
Water Clear |
1.9 |
2.5 |
3500 |
4500 |
30-40 |
| Green |
520-530 |
Water Clear |
2.9 |
3.5 |
4000 |
6500 |
30-40 |
| 5RG4SC |
Red |
620-635 |
Water Clear |
1.9 |
2.5 |
3500 |
4500 |
30-40 |
| Green |
520-530 |
Water Clear |
2.9 |
3.5 |
4000 |
6500 |
30-40 |
|
